UUID: jdXR5NacRT6MlYM56yddAA
Test Started: 30.10.2025 @ 10:58:18 UTC
Duration: 8 seconds.
| Test# | Details | Measurement | Min | Max | Status |
|---|---|---|---|---|---|
| 1 | Testerversion: DCP48M_TESTER_V3 | ||||
| 1 | MODBUS_COMMUNICATION Note: Modbus communication test |
1.000 | 0 | 1.000 | |
| 2 | PCB version: DCP48M_REV4 | ||||
| 2 | INITIAL_VOLTAGE_DUT Note: Initial DUT voltage measurement |
5.009 | 4.500 | 5.200 | |
| 3 | INITIAL_CURRENT_DUT Note: Initial DUT current measurement |
0.02600 | -0.5000 | 0.5000 | |
| 4 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
5.066 | 4.800 | 5.200 | |
| 5 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
4.994 | 4.800 | 5.200 | |
| 6 | VOLTAGE_NOLOAD_5.0V Note: No-load voltage test |
5.000 | 4.800 | 5.200 | |
| 7 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
9.116 | 8.640 | 9.360 | |
| 8 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
9.052 | 8.640 | 9.360 | |
| 9 | VOLTAGE_NOLOAD_9.0V Note: No-load voltage test |
9.000 | 8.640 | 9.360 | |
| 10 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
12.13 | 11.52 | 12.48 | |
| 11 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
12.03 | 11.52 | 12.48 | |
| 12 | VOLTAGE_NOLOAD_12.0V Note: No-load voltage test |
12.00 | 11.52 | 12.48 | |
| 13 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
31.17 | 29.76 | 32.24 | |
| 14 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
31.04 | 29.76 | 32.24 | |
| 15 | VOLTAGE_NOLOAD_MAX Note: Maximum no-load voltage test (31V) |
31.00 | 29.76 | 32.24 | |
| 16 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
0 | -0.5000 | 0.5000 | |
| 17 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
0 | -0.5000 | 0.5000 | |
| 18 | VOLTAGE_NOLOAD_MIN Note: Minimum no-load voltage test |
0 | -0.5000 | 0.5000 | |
| 19 | LOAD_TEST_SETVOLTAGE Note: Target output voltage for load test |
5.000 | 4.800 | 5.200 | |
| 20 | LOAD_TEST_SETCURRENT Note: Target output current for load test |
8.000 | 7.200 | 8.800 | |
| 21 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
5.067 | 4.800 | 5.200 | |
| 22 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
5.005 | 4.800 | 5.200 | |
| 23 | CURRENT_MEASUREMENT_MCP Note: MCP4725 current measurement in A (median of 10) |
7.942 | 7.200 | 8.800 | |
| 24 | CURRENT_MEASUREMENT_DUT Note: DUT current measurement in A (median of 10) |
7.763 | 7.200 | 8.800 | |
| 25 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
4.660 | 4.000 | 5.200 | |
| 26 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
5.065 | 4.000 | 5.200 | |
| 27 | LOAD_TEST_SETVOLTAGE Note: Target output voltage for load test |
9.000 | 8.640 | 9.360 | |
| 28 | LOAD_TEST_SETCURRENT Note: Target output current for load test |
5.000 | 4.500 | 5.500 | |
| 29 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
9.119 | 8.640 | 9.360 | |
| 30 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
9.029 | 8.640 | 9.360 | |
| 31 | CURRENT_MEASUREMENT_MCP Note: MCP4725 current measurement in A (median of 10) |
5.035 | 4.500 | 5.500 | |
| 32 | CURRENT_MEASUREMENT_DUT Note: DUT current measurement in A (median of 10) |
4.506 | 4.500 | 5.500 | |
| 33 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
8.824 | 7.840 | 9.360 | |
| 34 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
8.987 | 7.840 | 9.360 | |
| 35 | LOAD_TEST_SETVOLTAGE Note: Target output voltage for load test |
12.00 | 11.52 | 12.48 | |
| 36 | LOAD_TEST_SETCURRENT Note: Target output current for load test |
3.000 | 2.700 | 3.300 | |
| 37 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
12.04 | 11.52 | 12.48 | |
| 38 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
11.96 | 11.52 | 12.48 | |
| 39 | CURRENT_MEASUREMENT_MCP Note: MCP4725 current measurement in A (median of 10) |
2.964 | 2.700 | 3.300 | |
| 40 | CURRENT_MEASUREMENT_DUT Note: DUT current measurement in A (median of 10) |
2.934 | 2.700 | 3.300 | |
| 41 | VOLTAGE_MEASUREMENT_ADS Note: ADS1115 voltage measurement in V (median of 10) |
11.96 | 10.72 | 12.48 | |
| 42 | VOLTAGE_MEASUREMENT_DUT Note: DUT voltage measurement in V (median of 10) |
12.12 | 10.72 | 12.48 | |
| 43 | FINAL_TEST_RESULT Note: Overall result of all tests |
1.000 | 0 | 1.000 | |
